The Hospital Overbed Linear Light from Lacelesty Lighting is a versatile, multi-mode LED solution designed specifically for hospitals, healthcare facilities, and nursing rooms. Engineered for both indirect upward space lighting and focused downward illumination, this light provides two distinct 2-in-1 modes to enhance patient comfort and support critical care needs. The upward lighting features an asymmetric optical design that offers general lighting for examinations and a soothing sleep lighting option. The downward lighting, with its white louvre design, delivers low-glare directional illumination covering the entire bed—switchable between high-lumen examination mode and comfortable reading mode. With a maximum power of 90W, advanced phase dimming, and high CRI LED chips (Ra>90), this fixture ensures precise, uniform lighting and meets the rigorous demands of healthcare environments.
Product Features:
Multi-Mode Operation:
- Upward Lighting:
- Asymmetric optical design provides indirect space lighting to the ceiling.
- 2-in-1 modes: General lighting for examinations and a sleep lighting option for ambient comfort.
- Downward Lighting:
- White louvre design minimizes glare while directing light onto the bed.
- 2-in-1 modes: Switchable between high-lumen examination mode and comfortable reading mode.
- Upward Lighting:
Customizable Illumination:
- General Lighting Mode:
- Up to 60W, delivering 6000 lm max with tunable CCT options (2700K, 4000K, 6500K) and phase dimming (25%-50%-75%-100%).
- Reading Mode:
- 20W max with 2000 lm output at a fixed 4000K, designed for directional light on the bed.
- Examination Mode:
- Combines general and reading modes for enhanced brightness.
- Night Lighting Mode:
- 10W max, providing 1000 lm at a warm 1800K with an opal diffuser for gentle illumination.
- General Lighting Mode:
High-Performance & Durable:
- Constructed from premium Aluminum and PMMA with a sleek design.
- Equipped with high CRI (Ra>90) LED chips and a reliable BOKE LED driver.
- Designed to deliver uniform illumination with a 70° overall beam angle—featuring asymmetric distributions of 15° toward the ceiling and 15° toward the bed, reaching an effective 110° spread.
Optimized for Healthcare Environments:
- Ideal for hospitals, healthcare facilities, and nursing rooms—providing the right light levels for examination, reading, and patient comfort.
Robust Electrical & Dimmer Control:
- Operates on AC220-240V.
- Advanced phase dimming enables precise control of brightness across all modes.
Sleek Dimensions:
- Designed to be mounted over the bed with a footprint of L1017 x W156 x H58mm.
Product Parameters:
| Parameter | Specification |
|---|---|
| Product Name | Hospital Overbed Linear Light |
| Maximum Power | 90W MAX |
| Beam Angle | 70° overall; Asymmetric 15° toward ceiling, 15° toward bed; effective spread of 110° |
| Input Voltage | AC220-240V |
| Material | Aluminum + PMMA |
| LED Chip | High CRI (Ra >90) LED chips |
| LED Driver | BOKE |
| Size (mm) | L1017 x W156 x H58 |
| Lighting Modes: | General Lighting Mode: 60W max, 6000 lm max, CCT: 2700K/4000K/6500K (phase tunable, asymmetric diffuser directing light to ceiling, dimmable) Reading Mode: 20W max, 2000 lm max, CCT: 4000K only (asymmetric diffuser for directional light to bed, dimmable) Examination Mode: Combination of General + Reading modes for enhanced brightness Night Lighting Mode: 10W max, 1000 lm max, CCT: 1800K only (opal diffuser, dimmable at 25%-50%-75%-100%) |
| Application | Suitable for hospitals, healthcare facilities, and nursing rooms |
Enhance patient care and comfort with the Hospital Overbed Linear Light from Lacelesty Lighting—a smart, multi-mode lighting solution that offers precise control, robust performance, and adaptable illumination for every healthcare setting.
FAQ
Q1. Can I get a sample for quality check?
Lacelesty: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q2. How soon is the lead time?
Lacelesty: For sample order, 7-17 days if no stock. For bulk order, 15-35 days.
Q3. Can your products’ label, packaging, design be customized?
Lacelesty: Yes, we offer customization service on these.
Q4. How can we guarantee quality?
Lacelesty: Always a pre-production sample before mass production; Always final Inspection before shipment.
Q5. How do you ship the goods and how long does it take to arrive?
Lacelesty: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.
Q6. What is your payment way?
Lacelesty: Paypal / Visa / Western Union / online transfer / apply pay / T/T all works for us for payment.
